Featured Projects

AWN15 15t/h Boiler

Scope of Supply


Rental of 01 boiler as described below, belongings and ancillary equipment, instrumentation, command and control, 6m chimney stack , as well as, installation, commissioning, start up, training and initial operation.


Boiler 1

Manufacturer: ATA Aalborg, Service & Maintenance: SATHEL Energia S.A. – Equipment & Services, Model: AWN15, Type of Boiler: firetube, Design Pressure: 18 kg/cm², Boiler Nominal Capacity: 15.000 kg/h, Requested Operation Pressure: 15 kg / cm², Steam Temperature: Saturated, Feedwater Temperature: 80 ° C, Fuel: Natural Gas Oil 1A, CO2: 13% to 14%, O2: 2 to 4% %, Motors: 440 V, Control: 110 V Installation: Semi-sheltered.




Natural Gas
